P-2302R Series User’s Guide
67 Chapter 4 System Screens
4.7 Configuring Password
To change your Prestige’s password (recommended), click SYSTEM in the navigation panel,
and then the Password tab. The screen appears as shown.
Figure 17 Password
The following table describes the labels in this screen.
DDNS server auto
detect IP Address
Select this option to update the IP address of the host name(s) automatically
by the DDNS server. It is recommended that you select this option.
Select this option only when there are one or more NAT routers between the
Prestige and the DDNS server. This feature has the DDNS server
automatically detect and use the IP address of the NAT router that has a
public IP address.
Note: The DDNS server may not be able to detect the proper
IP address if there is an HTTP proxy server between the
Prestige and the DDNS server.
Use specified IP
Address
Select this option to update the IP address of the host name(s) to the IP
address specified below. Use this option if you have a static IP address.
IP Addr: Enter the IP address if you select the User Specify option.
Apply Click Apply to save your changes back to the Prestige.
Reset Click Reset to begin configuring this screen afresh.
Table 9 DDNS
LABEL DESCRIPTION
Table 10 Password
LABEL DESCRIPTION
Old Password Type the default password or the existing password you use to access the
system in this field.
New Password Type the new password in this field (up to 30 characters). Note that as you type
a password, the screen displays an asterisk (*) for each character you type.
