P-2302R Series User’s Guide
49 Chapter 2 Introducing the Web Configurator
2.5 Common Screen Command Buttons
The following table shows common command buttons found on many web configurator
screens.
MAINTENANCE Status This screen contains administrative and system-related information.
DHCP Table This screen shows which network clients are using the DHCP server.
Any IP This screen lists the devices that are using the Any IP feature to
communicate with the Prestige.
F/W Upload Use this screen to upload firmware to your Prestige
Configuration Use this screen to backup and restore the configuration or reset the
factory defaults to your Prestige.
Restart This screen allows you to reboot the Prestige without turning the
power off.
LOGOUT Click this label to exit the web configurator.
Table 2 Web Configurator Screens Summary (continued)
LINK TAB FUNCTION
Table 3 Common Screen Command Buttons
Apply Click Apply to save your changes back to the Prestige.
Reset/Cancel Click Reset or Cancel to begin configuring this screen afresh.
