P-2302R Series User’s Guide
Appendix A Product Specifications 340
Wall Mounting Specifications
Use two M4 x 30 mm screws to wall-mount the Prestige.
The centers of the holes for the wall-mounting screws should be 109 mm apart.
Power Adaptor Specifications
Static Routes 16 IP and 4 Bridge
Other Features Internal SPTGEN
DNS Proxy
Dynamic DNS
Any IP
IP Alias
Traffic Redirect
Table 140 Feature Specifications (continued)
Table 141 Prestige Power Adaptor Specifications
NORTH AMERICAN PLUG STANDARDS
AC Power Adapter Model DV-1215A
Input Power AC120Volts/60Hz/30W
Output Power AC12Volts/1.25A
Power Consumption 11 W
Safety Standards UL, CUL, CSA (UL 1310, CSA C22.2 No.223)
NORTH AMERICAN PLUG STANDARDS
AC Power Adapter Model AA-121A25
Input Power AC120Volts/60Hz/19W
Output Power AC 12Volts/ 1.25A
Power Consumption 11W
Safety Standards UL, CUL (UL 1310, CSA C22.2 No.223)
EUROPEAN PLUG STANDARDS
AC Power Adapter Model AA-121A3BN
Input Power AC230Volts/50Hz/140mA
Output Power AC12Volts/1.3A
Power Consumption 11W
Safety Standards ITS-GS, CE (EN 60950)
