P-2302R Series User’s Guide
Appendix A Product Specifications 338
APPENDIX A
Product Specifications
See also the introduction chapter for a general overview of the key features.
Specification Tables
Table 139 Device Specifications
Default IP Address 192.168.1.1
Default Management
Subnet Mask
255.255.255.0 (24 bits)
Default Password 1234
Dimensions 109 (Wide) x 105 (Deep) x 22 (High) mm
Weight 312 g
Ethernet Ports Two RJ-45, 10/100Mbps Half / Full Auto-negotiation, Auto-crossover
Ethernet ports
Phone Ports Two FXS (Foreign Exchange Station) POTS ports
Feeding Voltage On hook: -48V; Minimum Voltage: -20V
Off hook: -24V
Ringing Voltage P2302R: 40V RMS at 5 REN
P2302RL: 40V RMS at 3 REN
Line Ports (P2302RL
Only)
One FXO (Foreign Exchange Office) lifeline port
Operation Temperature 0º C ~ 40º C
Storage Temperature 0º ~ 60º C
Operation Humidity 10% ~ 85% RH
Storage Humidity 10% ~ 90% RH
