P-2302R Series User’s Guide
315 Chapter 34 System Maintenance
34.1.2 Command Usage
A list of commands can be found by typing help or ? at the command prompt. Always type
the full command. Type exit to return to the SMT main menu when finished.
Figure 182 Valid Commands Example
34.2 Call Control Support
The Prestige provides two call control functions: budget management and call history. Please
note that this menu is only applicable when Encapsulation is set to PPPoE in menu 4 or
menu 11.1.
The budget management function allows you to set a limit on the total outgoing call time of
the Prestige within certain times. When the total outgoing call time exceeds the limit, the
current call will be dropped and any future outgoing calls will be blocked.
To access the call control menu, select option 9 in menu 24 to go to Menu 24.9 — System
Maintenance — Call Control, as shown in the next table.
Figure 183 Menu 24.9 System Maintenance: Call Control
34.2.1 Budget Management
Menu 24.9.1 shows the budget management statistics for outgoing calls. Enter 1 from Menu
24.9 - System Maintenance - Call Control to bring up the following menu.
Copyright (c) 1994 - 2005 ZyXEL Communications Corp.
ras> ?
Valid commands are:
sys exit device ether
poe config ip ppp
bm voice dsp
Menu 24.9 - System Maintenance - Call Control
1. Budget Management
2. Call History
Enter Menu Selection Number:
