P-2302R Series User’s Guide
297 Chapter 32 System Information and Diagnosis
Figure 170 Menu 24.3.2 System Maintenance: Syslog Logging
You need to configure the syslog parameters described in the following table to activate syslog
then choose what you want to log.
Your Prestige sends five types of syslog messages. Some examples (not all Prestige specific)
of these syslog messages with their message formats are shown next:
Menu 24.3.2 - System Maintenance - Syslog Logging
Syslog:
Active= No
Syslog Server IP Address= 0.0.0.0
Log Facility= Local 1
Press ENTER to Confirm or ESC to Cancel:
Table 121 Menu 24.3.2 System Maintenance: Syslog Logging
PARAMETER DESCRIPTION
Syslog:
Active Press [SPACE BAR] and then [ENTER] to turn syslog on or off.
Syslog Server IP
Address
Enter the IP address of the syslog server that will log the CDR (Call Detail
Record) and system messages.
Log Facility Press [SPACE BAR] and then [ENTER] to select a Local option. The log facility
allows you to log the message to different files in the server. Please refer to the
documentation of your syslog program for more details.
When finished configuring this screen, press [ENTER] to confirm or [ESC] to cancel.
