P-2302R Series User’s Guide
Chapter 32 System Information and Diagnosis 296
Figure 168 Menu 24.2.2 System Maintenance: Change Console Port Speed
32.3 Log and Trace
To get to the log and trace menu:
1 Enter 24 to display Menu 24 – System Maintenance.
2 Enter 3 to display Menu 24.3 — System Maintenance - Log and Trace.
3 There are two logging facilities in the Prestige as shown in the next figure. The first is the
error logs and trace records that are stored locally. The second is the syslog facility for
message logging.
Figure 169 Menu 24.2 System Information and Console Port Speed
32.3.1 Syslog Logging
The Prestige uses the syslog facility to log the CDR (Call Detail Record) and system messages
to a syslog server. Syslog and accounting can be configured in Menu 24.3.2 — System
Maintenance - Syslog Logging, as shown next.
Menu 24.2.2 – System Maintenance – Change Console Port Speed
Console Port Speed: 9600
Press ENTER to Confirm or ESC to Cancel:
Menu 24.3 - System Maintenance - Log and Trace
2. Syslog Logging
4. Call-Triggering Packet
Please enter selection:
