P-2302R Series User’s Guide
295 Chapter 32 System Information and Diagnosis
Figure 167 Menu 24.2.1 System Maintenance: Information
The following table describes the fields in this menu.
32.2.2 Console Port Speed
Note: The console port is internal and reserved for technician use only.
You can set up different port speeds for the console port through Menu 24.2.2 – System
Maintenance – Console Port Speed. Your Prestige supports 9600 (default), 19200, 38400,
57600 and 115200 bps. Press [SPACE BAR] and then [ENTER] to select the desired speed in
menu 24.2.2, as shown in the following figure.
Menu 24.2.1 - System Maintenance - Information
Name: P2302R.Zyxel.com
Routing: IP
ZyNOS F/W Version: V3.60(MM.4)b1 | 11/08/2005
Country Code: 255
LAN
Ethernet Address: 00:13:49:52:78:33
IP Address: 192.168.1.1
IP Mask: 255.255.255.0
DHCP: Server
Press ESC or RETURN to Exit:
Table 120 Menu 24.2.1 System Maintenance: Information
FIELD DESCRIPTION
Name Displays the system name of your Prestige. This information can be changed
in Menu 1 – General Setup.
Routing Refers to the routing protocol used.
ZyNOS F/W Version Refers to the ZyNOS (ZyXEL Network Operating System) system firmware
version. ZyNOS is a registered trademark of ZyXEL Communications
Corporation.
Country Code This is the country code of the firmware.
LAN
Ethernet Address Refers to the Ethernet MAC (Media Access Control) of your Prestige.
IP Address This is the IP address of the Prestige in dotted decimal notation.
IP Mask This shows the subnet mask of the Prestige.
DHCP This field shows the DHCP setting (None, Relay or Server) of the Prestige.
