P-2302R Series User’s Guide
293 Chapter 32 System Information and Diagnosis
Figure 165 Menu 24.1 System Maintenance: Status
The following table describes the fields present in Menu 24.1 — System Maintenance —
Status. These fields are READ-ONLY and meant for diagnostic purposes. The upper right
corner of the screen shows the time and date according to the format you set in menu 24.10.
Menu 24.1 - System Maintenance - Status 07:15:35
Sat. Jan. 01, 2000
Port Status TxPkts RxPkts Cols Tx B/s Rx B/s Up Time
WAN Down 168 199 0 0 0 0:00:00
LAN 100M/Full 3040 2456 0 258 128 7:15:26
Port Ethernet Address IP Address IP Mask DHCP
WAN 00:13:49:52:78:34 192.168.2.5 255.255.255.0 None
LAN 00:13:49:52:78:33 192.168.1.1 255.255.255.0 Server
System up Time: 7:15:39
Name: P2302R.Zyxel.com
Routing: IP
ZyNOS F/W Version: V3.60(MM.4)b1 | 11/08/2005
Press Command:
COMMANDS: 1-Drop WAN 9-Reset Counters ESC-Exit
Table 119 System Maintenance: Status Menu Fields
FIELD DESCRIPTION
Port Identifies a port (WAN, LAN) on the Prestige.
Status Shows the port speed and duplex setting if you’re using Ethernet
Encapsulation and Down (line is down), idle (line (ppp) idle), dial (starting to
trigger a call) and drop (dropping a call) if you’re using PPPoE Encapsulation.
TxPkts The number of transmitted packets on this port.
RxPkts The number of received packets on this port.
Cols The number of collisions on this port.
Tx B/s Shows the transmission speed in Bytes per second on this port.
Rx B/s Shows the reception speed in Bytes per second on this port.
Up Time Total amount of time the line has been up.
Ethernet Address The Ethernet address of the port listed on the left.
IP Address The IP address of the port listed on the left.
IP Mask The IP mask of the port listed on the left.
DHCP The DHCP setting of the port listed on the left.
System up Time The total time the Prestige has been on.
