289 Chapter 30 Filter Configuration
30.5.1 Applying LAN Filters
LAN traffic filter sets may be useful to block certain packets, reduce traffic and prevent
security breaches. Go to menu 3.1 (shown next) and enter the number(s) of the filter set(s) that
you want to apply as appropriate. You can choose up to four filter sets (from twelve) by
entering their numbers separated by commas, e.g., 3, 4, 6, 11. Input filter sets filter incoming
traffic to the Prestige and output filter sets filter outgoing traffic from the Prestige. For PPPoE
encapsulation, you have the additional option of specifying remote node call filter sets.
Figure 161 Filtering LAN Traffic
30.5.2 Applying Remote Node Filters
Go to menu 11.5 (shown below – note that call filter sets are only present for PPPoE
encapsulation) and enter the number(s) of the filter set(s) as appropriate. You can cascade up
to four filter sets by entering their numbers separated by commas. The Prestige already has
filters to prevent NetBIOS traffic from triggering calls.
Figure 162 Filtering Remote Node Traffic
Menu 3.1 - LAN Port Filter Setup
Input Filter Sets:
protocol filters=
device filters=
Output Filter Sets:
protocol filters=
device filters=
Press ENTER to Confirm or ESC to Cancel:
Menu 11.5 - Remote Node Filter
Input Filter Sets:
protocol filters=
device filters=
Output Filter Sets:
protocol filters=
device filters=
Enter here to CONFIRM or ESC to CANCEL:
