281 Chapter 30 Filter Configuration
The protocol dependent filter rules abbreviation are listed as follows:
Refer to the next section for information on configuring the filter rules.
30.2.1 Configuring a Filter Rule
To configure a filter rule, type its number in Menu 21.1.x - Filter Rules Summary and press
[ENTER] to open menu 21.1.x.x for the rule.
To speed up filtering, all rules in a filter set must be of the same class, i.e., protocol filters or
generic filters. The class of a filter set is determined by the first rule that you create. When
applying the filter sets to a port, separate menu fields are provided for protocol and device
filter sets. If you include a protocol filter set in a device filter field or vice versa, the Prestige
will warn you and will not allow you to save.
30.2.2 Configuring a TCP/IP Filter Rule
This section shows you how to configure a TCP/IP filter rule. TCP/IP rules allow you to base
the rule on the fields in the IP and the upper layer protocol, for example, UDP and TCP
headers.
To configure TCP/IP rules, select TCP/IP Filter Rule from the Filter Type field and press
[ENTER] to open Menu 21.1.x.x - TCP/IP Filter Rule, as shown next.
Table 115 Rule Abbreviations Used
ABBREVIATION DESCRIPTION
IP
Pr Protocol
SA Source Address
SP Source Port number
DA Destination Address
DP Destination Port number
GEN
Off Offset
Len Length
