P-2302R Series User’s Guide
271 Chapter 28 Network Address Translation (NAT)
Note: Other applications such as some gaming programs are NAT unfriendly
because they embed addressing information in the data stream. These
applications won’t work through NAT even when using One-to-One and Many-
to-Many No Overload mapping types.
Follow the steps outlined in example 3 to configure these two menus as follows
Figure 144 Example 4: Menu 15.1.1.1 Address Mapping Rule.
After you’ve configured your rule, you should be able to check the settings in menu 15.1.1 as
shown next.
Figure 145 Example 4: Menu 15.1.1 Address Mapping Rules
28.6 Configuring Trigger Port Forwarding
Note: Only one LAN computer can use a trigger port (range) at a time.
Menu 15.1.1.1 Address Mapping Rule
Type= Many-One-to-One
Local IP:
Start= 192.168.1.10
End = 192.168.1.12
Global IP:
Start= 10.132.50.1
End = 10.132.50.3
Press ENTER to Confirm or ESC to Cancel:
Menu 15.1.1 - Address Mapping Rules
Set Name= Example4
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- -------------- -------------- --------------- --------------- ------
1. 192.168.1.10 192.168.1.12 10.132.50.1 10.132.50.3 M:M NO OV
2.
3.
4.
5.
6.
7.
8.
9.
10.
Action= Edit Select Rule=
Press ENTER to Confirm or ESC to Cancel:
