Chapter 28 Network Address Translation (NAT) 260
Figure 127 Menu 15 NAT Setup
28.3.1 Address Mapping Sets
Enter 1 to bring up Menu 15.1 — Address Mapping Sets.
Figure 128 Menu 15.1 Address Mapping Sets
Enter 255 to display the next screen (see Section 12.3 on page 131 for more on SUA). The
fields in this menu cannot be changed.
Figure 129 Menu 15.1.255 SUA Address Mapping Rules
The following table explains the fields in this menu.
Menu 15 - NAT Setup
1. Address Mapping Sets
2. Port Forwarding Setup
3. Trigger Port Setup
Enter Menu Selection Number:
Menu 15.1 - Address Mapping Sets
1. NAT_SET
255. SUA (read only)
Enter Menu Selection Number:
Menu 15.1.255 - Address Mapping Rules
Set Name= SUA
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- -------------- --------------- --------------- --------------- ------
1. 0.0.0.0 255.255.255.255 0.0.0.0 M-1
2. 0.0.0.0 Server
3.
4.
5.
6.
7.
8.
9.
10.
Press ENTER to Confirm or ESC to Cancel:
