P-2302R Series User’s Guide
Chapter 28 Network Address Translation (NAT) 258
CHAPTER 28
Network Address Translation
(NAT)
This chapter discusses how to configure NAT on the Prestige.
28.1 NAT Introduction
See Chapter 12 on page 128 for background information on NAT.
28.2 Applying NAT
You apply NAT via menus 4 or 11.3 as displayed next. The next figure shows you how to
apply NAT for Internet access in menu 4. Enter 4 from the main menu to go to Menu 4 -
Internet Access Setup.
Figure 125 Menu 4 Applying NAT for Internet Access
The following figure shows how you apply NAT to the remote node in menu 11.1.
1 Enter 11 from the main menu.
2 When menu 11 appears, as shown in the following figure, type the number of the remote
node that you want to configure.
Menu 4 - Internet Access Setup
ISP's Name= MyISP
Encapsulation= Ethernet
Service Type= Standard
My Login= N/A
Password= N/A
Retype to Confirm= N/A
Login Server= N/A
IP Address Assignment= Dynamic
IP Address= N/A
IP Subnet Mask= N/A
Gateway IP Address= N/A
Network Address Translation= SUA Only
Press ENTER to Confirm or ESC to Cancel:
