P-2302R Series User’s Guide
Chapter 26 Remote Node Configuration 248
26.2.2 PPPoE Encapsulation
The Prestige supports PPPoE (Point-to-Point Protocol over Ethernet). You can only use
PPPoE encapsulation when you’re using the Prestige with a DSL modem as the WAN device.
If you change the Encapsulation to PPPoE, then you will see the next screen. Please see the
appendix for more information on PPPoE.
Route This field refers to the protocol that will be routed by your Prestige – IP is the only
option for the Prestige.
Apply Alias Press [SPACE BAR] to select an IP alias if you want to use one for this static
route. Leave None selected to use the regular LAN IP address.
Edit IP This field leads to a “hidden” menu. Press [SPACE BAR] to select Yes and press
[ENTER] to go to Menu 11.3 - Remote Node Network Layer Options.
Session Options
Edit Filter Sets This field leads to another “hidden” menu. Use [SPACE BAR] to select Yes and
press [ENTER] to open menu 11.5 to edit the filter sets. See Section 26.4 on page
252 for more details.
Edit Traffic
Redirect
Press [SPACE BAR] to select Yes or No.
Select Yes and press [ENTER] to configure Menu 11.6 Traffic Redirect Setup.
Select No (default) if you do not want to configure this feature.
Once you have configured this menu, press [ENTER] at the message “Press ENTER to Confirm...” to
save your configuration, or press [ESC] at any time to cancel.
Table 104 Menu 11.1 Remote Node Profile for Ethernet Encapsulation (continued)
FIELD DESCRIPTION
