P-2302R Series User’s Guide
247 Chapter 26 Remote Node Configuration
Figure 117 Menu 11.1 Remote Node Profile for Ethernet Encapsulation
The following table describes the fields in this menu.
Menu 11.1 - Remote Node Profile
Rem Node Name= MyISP Route= IP
Active= Yes
Apply Alias= None
Encapsulation= Ethernet Edit IP= No
Service Type= Standard Session Options:
Service Name= N/A Edit Filter Sets= No
Outgoing:
My Login= N/A
My Password= N/A Edit Traffic Redirect= No
Retype to Confirm= N/A
Server= N/A
Press ENTER to Confirm or ESC to Cancel:
Table 104 Menu 11.1 Remote Node Profile for Ethernet Encapsulation
FIELD DESCRIPTION
Rem Node Name Enter a descriptive name for the remote node. This field can be up to eight
characters.
Active Press [SPACE BAR] and then [ENTER] to select Yes (activate remote node) or
No (deactivate remote node).
Encapsulation Ethernet is the default encapsulation. Press [SPACE BAR] and then [ENTER] to
change to PPPoE encapsulation.
Service Type Press [SPACE BAR] and then [ENTER] to select from Standard, RR-Toshiba
(RoadRunner Toshiba authentication method), RR-Manager (RoadRunner
Manager authentication method), or RR-Telstra. Choose one of the RoadRunner
methods if your ISP is Time Warner's RoadRunner; otherwise choose Standard.
Outgoing
My Login This field is applicable for PPPoE encapsulation only. Enter the login name
assigned by your ISP when the Prestige calls this remote node. Some ISPs
append this field to the Service Name field above (e.g., jim@poellc) to access the
PPPoE server.
My Password Enter the password assigned by your ISP when the Prestige calls this remote
node. Valid for PPPoE encapsulation only.
Retype to Confirm Type your password again to make sure that you have entered it correctly.
Server This field is valid only when RoadRunner is selected in the Service Type field.
The Prestige will find the RoadRunner Server IP automatically if this field is left
blank. If it does not, then you must enter the authentication server IP address
here.
