25.3 Configuring the PPPoE Client
If you enable PPPoE in menu 4, you will see the next screen. For more information on PPPoE,
please see the appendix.
Table 102 Internet Access Setup (Ethernet)
FIELD DESCRIPTION
ISP’s Name Enter the name of your Internet Service Provider, e.g., myISP. This
information is for identification purposes only.
Encapsulation Press [SPACE BAR] and then press [ENTER] to choose Ethernet. The
encapsulation method influences your choices for the IP Address field.
Service Type Press [SPACE BAR] and then [ENTER] to select Standard, RR-Toshiba
(RoadRunner Toshiba authentication method), RR-Manager (RoadRunner
Manager authentication method) or RR-Telstra. Choose a RoadRunner flavor
if your ISP is Time Warner's RoadRunner; otherwise choose Standard.
Note: DSL users must choose the Standard option only. The My Login, My Password and Login
Server fields are not applicable in this case.
My Login Enter the login name given to you by your ISP.
My Password Type your password again for confirmation.
Retype to Confirm Enter your password again to make sure that you have entered is correctly.
Login Server The Prestige will find the RoadRunner Server IP if this field is left blank. If it
does not, then you must enter the authentication server IP address.
IP Address Assignment If your ISP did not assign you a fixed IP address, press [SPACE BAR] and
then [ENTER] to select Dynamic, otherwise select Static and enter the IP
address and subnet mask in the following fields.
IP Address Enter the (fixed) IP address assigned to you by your ISP (static IP address
assignment is selected in the previous field).
IP Subnet Mask Enter the subnet mask associated with your static IP.
Gateway IP Address Enter the gateway IP address associated with your static IP.
Network Address
Translation
Network Address Translation (NAT) allows the translation of an Internet
protocol address used within one network (for example a private IP address
used in a local network) to a different IP address known within another
network (for example a public IP address used on the Internet).
Choose None to disable NAT.
Choose SUA Only if you have a single public IP address. SUA (Single User
Account) is a subset of NAT that supports two types of mapping: Many-to-
One and Server.
Choose Full Feature if you have multiple public IP addresses. Full Feature
mapping types include: One-to-One, Many-to-One (SUA/PAT), Many-to-
Many Overload, Many- One-to-One and Server. When you select Full
Feature you must configure at least one address mapping set!
Please see Chapter 12 on page 128 for a more detailed discussion on the
Network Address Translation feature.
When you have completed this menu, press [ENTER] at the prompt “Press ENTER to Confirm…” to
save your configuration, or press [ESC] at any time to cancel.
