P-2302R Series User’s Guide
Chapter 22 General Setup 232
Figure 109 Menu 1.1 Configure Dynamic DNS
Follow the instructions in the next table to configure Dynamic DNS parameters.
Menu 1.1 - Configure Dynamic DNS
Service Provider= WWW.DynDNS.ORG
Active= No
DDNS Type= DynamicDNS
Host Name 1=
Host Name 2=
Host Name 3=
Username=
Password= ********
Enable Wildcard Option= No
Enable Off Line Option= N/A
IP Address Update Policy:
DDNS Server Auto Detect IP Address= No
Use Specified IP Address= No
Use IP Address= N/A
Press ENTER to Confirm or ESC to Cancel:
Press Space Bar to Toggle.
Table 97 Menu 1.1 Configure Dynamic DNS
FIELD DESCRIPTION
Service Provider This is the name of your Dynamic DNS service provider.
Active Press [SPACE BAR] to select Yes and then press [ENTER] to make dynamic DNS
active.
DDNSType Press [SPACE BAR] and then [ENTER] to select DynamicDNS if you have a
dynamic IP address(es). Select StaticDNS if you have a static IP address(es).
Select CustomDNS to have dyns.org provide DNS service for a domain name that
you already have from a source other than dyndns.org.
Host 1- 3 Enter your host name(s) in the fields provided. You can specify up to two host
names separated by a comma in each field.
USER Enter your user name.
Password Enter the password assigned to you.
Enable Wildcard
Option
Your Prestige supports DYNDNS Wildcard. Press [SPACE BAR] and then [ENTER]
to select Yes or No This field is N/A when you choose DDNS client as your service
provider.
Enable Offline
Option
This field is only available when CustomDNS is selected in the DDNS Type field.
Press [SPACE BAR] and then [ENTER] to select Yes. When Yes is selected,
http:/
/www.dyndns.org/ traffic is redirected to a URL that you have previously specified
(see www.dyndns.org
for details).
