P-2302R Series User’s Guide
231 Chapter 22 General Setup
22.2.1 Procedure to Configure Dynamic DNS
Note: If you have a private WAN IP address, then you cannot use Dynamic DNS
To configure Dynamic DNS, go to Menu 1 — General Setup and select Yes in the Edit
Dynamic DNS field. Press [ENTER] to display Menu 1.1— Configure Dynamic DNS as
shown next.
First System DNS
Server
Second System
DNS Server
Third System DNS
Server
DNS (Domain Name System) is for mapping a domain name to its corresponding
IP address and vice versa. The DNS server is extremely important because
without it, you must know the IP address of a machine before you can access it.
The Prestige uses a system DNS server (in the order you specify here) to resolve
domain names for DDNS and the time server.
Press [SPACE BAR] and then [ENTER] to select an option. Select From ISP if
your ISP dynamically assigns DNS server information (and the Prestige's WAN IP
address). The IP Address field below displays the (read-only) DNS server IP
address that the ISP assigns.
Select User-Defined if you have the IP address of a DNS server. Enter the DNS
server's IP address in the IP Address field. If you select User-Defined, but leave
the IP address set to 0.0.0.0, User-Defined changes to None after you save your
changes. If you set a second choice to User-Defined, and enter the same IP
address, the second User-Defined changes to None after you save your
changes.
Select None if you do not want to configure DNS servers. If you do not configure
a system DNS server, you must use IP addresses when configuring DDNS and
the time server.
Edit Dynamic DNS Press [SPACE BAR] and then [ENTER] to select Yes or No (default). Select Yes
to configure Menu 1.1: Configure Dynamic DNS discussed next.
When you have completed this menu, press [ENTER] at the prompt “Press ENTER to Confirm…” to
save your configuration, or press [ESC] at any time to cancel.
Table 96 Menu 1 General Setup (continued)
FIELD DESCRIPTION
