P-2302R Series User’s Guide
Chapter 22 General Setup 230
CHAPTER 22
General Setup
Menu 1 - General Setup contains administrative and system-related information.
22.1 General Setup Introduction
See Chapter 4 on page 62 for background information on general setup.
22.2 General Setup Configuration
Enter 1 in the Main Menu to open Menu 1 — General Setup (shown next)
Figure 108 Menu 1 General Setup.
The following table describes the fields in this menu.
Menu 1 - General Setup
System Name=
Domain Name= zyxel.com.tw
First System DNS Server= From ISP
IP Address= N/A
Second System DNS Server= From ISP
IP Address= N/A
Third System DNS Server= From ISP
IP Address= N/A
Edit Dynamic DNS= No
Press ENTER to Confirm or ESC to Cancel:
Table 96 Menu 1 General Setup
FIELD DESCRIPTION
System Name Choose a descriptive name for identification purposes. It is recommended you
enter your computer’s “Computer name” in this field. This name can be up to 30
alphanumeric characters long. Spaces are not allowed, but dashes “-” and
underscores "_" are accepted.
Domain Name Enter the domain name (if you know it) here. If you leave this field blank, the ISP
may assign a domain name via DHCP. You can go to menu 24.8 and type "sys
domain name" to see the current domain name used by your router. Use up to 38
alphanumeric characters. Spaces are not allowed, but dashes “-” and periods "."
are accepted.
The domain name entered by you is given priority over the ISP assigned domain
name. If you want to clear this field just press [SPACE BAR] and then [ENTER].
