P-2302R Series User’s Guide
Chapter 21 Introducing the SMT 226
Figure 106 SMT Main Menu
21.3.1 System Management Terminal Interface Summary
The following table describes the fields in the previous screen.
Copyright (c) 1994 - 2005 ZyXEL Communications Corp.
Prestige 2302R Main Menu
Getting Started Advanced Management
1. General Setup 21. Filter and Firewall Setup
2. WAN Setup 22. SNMP Configuration
3. LAN Setup 23. System Password
4. Internet Access Setup 24. System Maintenance
26. Schedule Setup
Advanced Applications
11. Remote Node Setup
12. Static Routing Setup
15. NAT Setup
99. Exit
Enter Menu Selection Number:
Table 94 Main Menu Summary
# MENU TITLE DESCRIPTION
1 General Setup Use this menu to set up your general information.
2 WAN Setup Use this menu to clone a MAC address from a computer on your
LAN.
3 LAN Setup Use this menu to set up your LAN connection.
4 Internet Access Setup Configure your Internet Access setup (Internet address, gateway,
login, etc.) with this menu.
11 Remote Node Setup Use this menu to configure detailed remote node settings (your
ISP is also a remote node) as well as apply WAN filters.
12 Static Routing Setup Use this menu to set up static routes.
15 NAT Setup Use this menu to specify inside servers when NAT is enabled.
21 Filter and Firewall Setup Configure filters and activate/deactivate the firewall.
22 SNMP Configuration Use this menu to set up SNMP related parameters.
23 System Password Use this menu to change your password.
24 System Maintenance This menu provides system status, diagnostics, software upload,
etc.
26 Schedule Setup Use this menu to schedule outgoing calls.
99 Exit Use this to exit from SMT and return to a blank screen.
