P-2302R Series User’s Guide
Chapter 21 Introducing the SMT 224
CHAPTER 21
Introducing the SMT
This chapter explains how to access and navigate the System Management Terminal and gives
an overview of its menus.
21.1 SMT Introduction
The Prestige’s SMT (System Management Terminal) is a menu-driven interface that you can
access through a telnet connection. This chapter shows you how to access the SMT (System
Management Terminal) menus, how to navigate the SMT and how to configure SMT menus.
21.2 Accessing the SMT via Telnet
The following procedure details how to telnet into your Prestige.
1 In Windows, click Start (usually in the bottom left corner), Run and then type “telnet
192.168.1.1” (the default IP address) and click OK.
2 For your first login, enter the default password “1234”. As you type the password, the
screen displays an asterisk “*” for each character you type.
Figure 105 Login Screen
3 After entering the password you will see the main menu.
Please note that if there is no activity for longer than five minutes (default timeout period)
after you log in, your Prestige will automatically log you out. You will then have to telnet into
the Prestige again. You can use the web configurator or the CI commands to change the
inactivity time out period.
21.3 Navigating the SMT Interface
The SMT (System Management Terminal) is the interface that you use to configure your
Prestige.
Password : xxxx
