P-2302R Series User’s Guide
221 Chapter 20 Maintenance
20.6.2 Restore Configuration
Restore Configuration allows you to upload a new or previously saved configuration file
from your computer to your Prestige.
Note: Do not turn off the device while configuration file upload is in progress.
After you see a “configuration upload successful” screen, you must then wait one minute
before logging into the device again.
Figure 101 Configuration Upload Successful
The device automatically restarts in this time causing a temporary network disconnect. In
some operating systems, you may see the following icon on your desktop.
Figure 102 Network Temporarily Disconnected
If you uploaded the default configuration file you may need to change the IP address of your
computer to be in the same subnet as that of the default management IP address (192.168.5.1).
See your Quick Start Guide or the appendices for details on how to set up your computer’s IP
address.
Table 92 Restore Configuration
LABEL DESCRIPTION
File Path Type in the location of the file you want to upload in this field or click Browse... to find it.
Browse... Click Browse... to find the file you want to upload. Remember that you must decompress
compressed (.ZIP) files before you can upload them.
Upload Click Upload to begin the upload process.
