P-2302R Series User’s Guide

Chapter 20 Maintenance 218

Figure 96 Firmware Upload

The following table describes the labels in this screen.

Note: Do not turn off the device while firmware upload is in progress!

After you see the Firmware Upload in Process screen, wait two minutes before logging into

the device again.

Table 91 Firmware Upload

LABEL DESCRIPTION

File Path Type in the location of the file you want to upload in this field or click Browse... to find it.

Browse... Click Browse... to find the .bin file you want to upload. Remember that you must

decompress compressed (.zip) files before you can upload them.

Upload Click Upload to begin the upload process. This process may take up to two minutes.
