P-2302R Series User’s Guide
217 Chapter 20 Maintenance
Figure 95 Any IP Table
The following table describes the labels in this screen.
20.5 F/W Upload Screen
Find firmware at www.zyxel.com in a file that (usually) uses the system model name with a
"*.bin" extension, e.g., "Prestige.bin". The upload process uses HTTP (Hypertext Transfer
Protocol) and may take up to two minutes. After a successful upload, the system will reboot.
Click MAINTENANCE in the navigation panel and then the F/W UPLOAD tab. Follow the
instructions in this screen to upload firmware to your Prestige.
Note: Only use firmware for your Prestige’s specific model. Refer to the label on the
bottom of your Prestige.
Table 90 Any IP Table
LABEL DESCRIPTION
# This field displays the index number.
IP Address
This field displays the IP address of the network device.
MAC Address This field displays the MAC (Media Access Control) address of the computer with the
displayed IP address.
Every Ethernet device has a unique MAC address. The MAC address is assigned at
the factory and consists of six pairs of hexadecimal characters, for example,
00:A0:C5:00:00:02.
Refresh Click Refresh to update this screen.
