P-2302R Series User’s Guide
193 Chapter 18 Logs
Table 69 RTP Logs
LOG MESSAGE DESCRIPTION
Error, RTP init fail The initialization of an RTP session failed.
Error, Call fail: RTP
connect fail
A VoIP phone call failed because the RTP session could not be
established.
Error, RTP connection
cannot close
The termination of an RTP session failed.
Table 70 FSM Logs: Caller Side
LOG MESSAGE DESCRIPTION
VoIP Call Start Ph[Phone
Port Number] <- Outgoing
Call Number
Someone used a phone connected to the listed phone port to
initiate a VoIP call to the listed destination.
VoIP Call Established
Ph[Phone Port] -> Outgoing
Call Number
Someone used a phone connected to the listed phone port to
make a VoIP call to the listed destination.
VoIP Call End Phone[Phone
Port]
A VoIP phone call made from a phone connected to the listed
phone port has terminated.
Table 71 FSM Logs: Callee Side
LOG MESSAGE DESCRIPTION
VoIP Call Start from
SIP[SIP Port Number]
A VoIP phone call came to the Prestige from the listed SIP number.
VoIP Call Established
Ph[Phone Port] <-
Outgoing Call Number
A VoIP phone call was set up from the listed SIP number to the
Prestige.
VoIP Call End
Phone[Phone Port]
A VoIP phone call that came into the Prestige has terminated.
Table 72 Lifeline Logs
LOG MESSAGE DESCRIPTION
PSTN Call Start A PSTN call has been initiated.
PSTN Call End A PSTN call has terminated.
PSTN Call Established A PSTN call has been set up.
