P-2302R Series User’s Guide
Chapter 18 Logs 186
Successful WEB login Someone has logged on to the device's web configurator
interface.
WEB login failed Someone has failed to log on to the device's web configurator
interface.
TELNET Login Successfully Someone has logged on to the router via telnet.
TELNET Login Fail Someone has failed to log on to the router via telnet.
Successful FTP login Someone has logged on to the device via ftp.
FTP login failed Someone has failed to log on to the device via ftp.
NAT Session Table is Full! The maximum number of NAT session table entries has been
exceeded and the table is full.
Time initialized by Daytime
Server
The device got the time and date from the Daytime server.
Time initialized by Time
server
The device got the time and date from the time server.
Time initialized by NTP
server
The device got the time and date from the NTP server.
Connect to Daytime server
fail
The device was not able to connect to the Daytime server.
Connect to Time server fail The device was not able to connect to the Time server.
Connect to NTP server fail The device was not able to connect to the NTP server.
Too large ICMP packet has
been dropped
The device dropped an ICMP packet that was too large.
Configuration Change: PC =
0x%x, Task ID = 0x%x
The device is saving configuration changes.
Table 57 Access Control Logs
LOG MESSAGE DESCRIPTION
Firewall default policy: [ TCP |
UDP | IGMP | ESP | GRE | OSPF ]
<Packet Direction>
Attempted TCP/UDP/IGMP/ESP/GRE/OSPF access
matched the default policy and was blocked or forwarded
according to the default policy’s setting.
Firewall rule [NOT] match:[ TCP
| UDP | IGMP | ESP | GRE | OSPF ]
<Packet Direction>, <rule:%d>
Attempted TCP/UDP/IGMP/ESP/GRE/OSPF access
matched (or did not match) a configured firewall rule
(denoted by its number) and was blocked or forwarded
according to the rule.
Triangle route packet forwarded:
[ TCP | UDP | IGMP | ESP | GRE |
OSPF ]
The firewall allowed a triangle route session to pass
through.
Packet without a NAT table entry
blocked: [ TCP | UDP | IGMP | ESP
| GRE | OSPF ]
The router blocked a packet that didn't have a
corresponding NAT table entry.
Router sent blocked web site
message: TCP
The router sent a message to notify a user that the router
blocked access to a web site that the user requested.
Table 56 System Maintenance Logs (continued)
LOG MESSAGE DESCRIPTION
