P-2302R Series User’s Guide
Chapter 16 Remote Management Screens 164
16.6.1 Supported MIBs
The Prestige supports MIB II as defined in RFC 1213 and RFC 1215. The focus of the MIBs is
to let administrators collect statistical data and monitor status and performance.
16.6.2 SNMP Traps
The Prestige will send traps to the SNMP manager when any one of the following events
occurs:
Table 47 SNMPv1 Traps
TRAP # TRAP NAME DESCRIPTION
0 coldStart (defined in RFC-1215) A trap is sent after booting (power on).
1 warmStart (defined in RFC-1215) A trap is sent after booting (software reboot).
4 authenticationFailure (defined in
RFC-1215)
A trap is sent to the manager when receiving any
SNMP get or set requirements with the wrong
community (password).
6 whyReboot (defined in ZYXEL-
MIB)
A trap is sent with the reason of restart before
rebooting when the system is going to restart (warm
start).
6a For intentional reboot : A trap is sent with the message "System reboot by
user!" if reboot is done intentionally, (for example,
download new files, CI command "sys reboot", etc.).
6b For fatal error : A trap is sent with the message of the fatal code if the
system reboots because of fatal errors.
Table 48 SNMPv2 Traps
TRAP NAME
OBJECT IDENTIFIER #
(OID)
DESCRIPTION
Generic Traps
coldStart 1.3.6.1.6.3.1.1.5.1 This trap is sent after booting (power on). This
trap is defined in RFC-1215.
warmStart 1.3.6.1.6.3.1.1.5.2 This trap is sent after booting (software
reboot). This trap is defined in RFC-1215.
linkDown 1.3.6.1.6.3.1.1.5.3 This trap is sent when the Ethernet link is
down.
linkUp 1.3.6.1.6.3.1.1.5.4 This trap is sent when the Ethernet link is up.
authenticationFailure
(defined in RFC-1215)
1.3.6.1.6.3.1.1.5.5 The device sends this trap when it receives
any SNMP get or set requirements with the
wrong community (password).
Note: snmpEnableAuthenTraps, OID
1.3.6.1.2.1.11.30 (defined in RFC 1214 and
RFC 1907) must be enabled on in order for the
device to send authenticationFailure traps.
Use a MIB browser to enable or disable
snmpEnableAuthenTraps.
