P-2302R Series User’s Guide
161 Chapter 16 Remote Management Screens
Figure 63 Remote Management: FTP
The following table describes the labels in this screen.
16.5 Configuring WWW
To change your Prestige’s remote HTTP access settings, click REMOTE MGMT to display
the WWW screen.
Table 45 Remote Management: FTP
LABEL DESCRIPTION
Server Port You may change the server port number for a service if needed, however you must
use the same port number in order to use that service for remote management.
Server Access Select the interface(s) through which a computer may access the Prestige using
this service.
Secured Client IP
Address
A secured client is a “trusted” computer that is allowed to communicate with the
Prestige using this service.
Select All to allow any computer to access the Prestige using this service.
Choose Selected to just allow the computer with the IP address that you specify to
access the Prestige using this service.
Apply Click Apply to save your customized settings and exit this screen.
Reset Click Reset to begin configuring this screen afresh.
