P-2302R Series User’s Guide
Chapter 16 Remote Management Screens 160
Figure 62 Remote Management: Telnet
The following table describes the labels in this screen.
16.4 Configuring FTP
You can upload and download the Prestige’s firmware and configuration files using FTP,
please see the chapter on firmware and configuration file maintenance for details. To use this
feature, your computer must have an FTP client.
To change your Prestige’s FTP settings, click REMOTE MGMT, then the FTP tab. The
screen appears as shown.
Table 44 Remote Management: Telnet
LABEL DESCRIPTION
Server Port You may change the server port number for a service if needed, however you must
use the same port number in order to use that service for remote management.
Server Access Select the interface(s) through which a computer may access the Prestige using this
service.
Secured Client IP
Address
A secured client is a “trusted” computer that is allowed to communicate with the
Prestige using this service.
Select All to allow any computer to access the Prestige using this service.
Choose Selected to just allow the computer with the IP address that you specify to
access the Prestige using this service.
Apply Click Apply to save your customized settings and exit this screen.
Reset Click Reset to begin configuring this screen afresh.
