P-2302R Series User’s Guide
Chapter 15 Content Filtering 156
Enable URL
Keyword Blocking
The Prestige can block Web sites with URLs that contain certain keywords in the
domain name or IP address. For example, if the keyword "bad" was enabled, all
sites containing this keyword in the domain name or IP address will be blocked,
e.g., URL http://www.website.com/bad.html would be blocked. Select this check
box to enable this feature.
Keyword Type a keyword in this field. You may use any character (up to 64 characters).
Wildcards are not allowed. You can also enter a numerical IP address.
Keyword List This list displays the keywords already added.
Add Click Add after you have typed a keyword.
Repeat this procedure to add other keywords. Up to 64 keywords are allowed.
When you try to access a web page containing a keyword, you will get a message
telling you that the content filter is blocking this request.
Delete Highlight a keyword in the lower box and click Delete to remove it. The keyword
disappears from the text box after you click Apply.
Clear All Click this button to remove all of the listed keywords.
Denied Access
Message
Enter a message to be displayed when the Prestige’s content filter feature blocks
a user’s access to a web site.
Day to Block Select check boxes for the days that you want the Prestige to perform content
filtering. Select the Everyday check box to have content filtering turned on all
days of the week.
Time of Day to
Block
Time of Day to Block allows the administrator to define during which time periods
content filtering is enabled. Time of Day to Block restrictions only apply to the
keywords (see above). Restrict web server data, such as ActiveX, Java, Cookies
and Web Proxy are not affected.
Enter the time period, in 24-hour format, during which content filtering will be
enforced. Select the All Day check box to have content filtering always active on
the days selected in Day to Block with time of day limitations not enforced.
Apply Click Apply to save your changes.
Reset Click Reset to begin configuring this screen afresh
Table 43 Content Filter
LABEL DESCRIPTION
