135 Chapter 12 Network Address Translation (NAT) Screens
12.5 Configuring Address Mapping
Ordering your rules is important because the Prestige applies the rules in the order that you
specify. When a rule matches the current packet, the Prestige takes the corresponding action
and the remaining rules are ignored. If there are any empty rules before your new configured
rule, your configured rule will be pushed up by that number of empty rules. For example, if
you have already configured rules 1 to 6 in your current set and now you configure rule
number 9. In the set summary screen, the new rule will be rule 7, not 9. Now if you delete rule
4, rules 5 to 7 will be pushed up by 1 rule, so old rules 5, 6 and 7 become new rules 4, 5 and 6.
To change your Prestige’s address mapping settings, click SUA/NAT, then the Address
Mapping tab. The screen appears as shown.
End Port Type a port number in this field.
To forward only one port, type the port number in the Start Port field above and
then type it again in this field.
To forward a series of ports, type the last port number in a series that begins with
the port number in the Start Port field above.
Server IP
Address
Enter the inside IP address of the server here.
Apply Click Apply to save your changes back to the Prestige.
Reset Click Reset to begin configuring this screen afresh.
Table 35 SUA/NAT Setup
LABEL DESCRIPTION
