P-2302R Series User’s Guide
Chapter 9 Phone 116
• Put the first call on hold and answer the second call.
Press the flash key and then “2”.
9.3.2.3 European Call Transfer
Do the following to transfer an incoming call (that you have answered) to another phone.
1 Press the flash key to put the caller on hold.
2 When you hear the dial tone, dial “*98#” followed by the number to which you want to
transfer the call. to operate the Intercom.
3 After you hear the ring signal or the second party answers it, hang up the phone.
9.3.2.4 European Three-Way Conference
Use the following steps to make three-way conference calls.
1 When you are on the phone talking to someone, place the flash key to put the caller on
hold and get a dial tone.
2 Dial a phone number directly to make another call.
3 When the second call is answered, press the flash key and press “3” to create a three-way
conversation.
4 Hang up the phone to drop the connection.
5 If you want to separate the activated three-way conference into two individual
connections (one is on-line, the other is on hold), press the flash key and press “2”.
9.3.3 USA Type Supplementary Services
This section describes how to use supplementary phone services with the USA Type Call
Service Mode. Commands for supplementary services are listed in the table below.
After pressing the flash key, if you do not issue the sub-command before the default sub-
command timeout (2 seconds) expires or issue an invalid sub-command, the current operation
will be aborted.
Table 27 USA Type Flash Key Commands
COMMAND SUB-COMMAND DESCRIPTION
Flash Put a current call on hold to place a second call. After the second
call is successful, press the flash key again to have a three-way
conference call.
Put a current call on hold to answer an incoming call.
Flash *98# Transfer the call to another phone.
