Cable Router User's Guide

Appendix A Product Specifications
P-2900-4HB User’s Guide
92
Maximum Data
rate
30 Mbps for 64 QAM
40 Mbps for 256 QAM
Symbol Rates 5.057 Msym/s for 64 QAM
5.361 Msym/s for 256 QAM
Operating Level -15 to +15 dBmV
UPSTREAM CHANNEL
Frequency Range 5 to 42 Mhz
Bandwidth 200 Khz/400 Khz/800 Khz
1.6 Mhz/3.2 Mhz/6.4* Mhz
Output Impedance 75 ohms (nominal)
Modulation 8*/16/32*/64*/128* QAM or QPSK
Maximum Data
Rate
30 Mbps
Symbol Rates 160, 320, 640, 1280, 2560 and 5120* Ksym/s
Operating Level TDMA:
+8 to +54 dBmV (32 QAM, 64QAM)
+8 to +55 dBmV (8 QAM, 16QAM)
+8 to +58 dBmV (QPSK)
S-CDMA:
+8 to +53 dBmV (all modulation types)
Table 23 Firmware Features
FEATURE DESCRIPTION
Default IP Address 192.168.1.1
Default Subnet Mask 255.255.255.0 (24 bits)
Default Administrator
User Name
admin
Default Administrator
Password
1234
High Speed Internet
Access
The ZyXEL Device supports transmission speeds of up to 43
Mbps upstream and 30 Mbps downstream. Actual speeds
attained depend on your cable operator’s CMTS (Cable Modem
Termination System).
Note: The standard your cable operator supports
determines the maximum upstream and downstream
speeds attainable. Actual speeds attained depend on
the distance from the cable operator’s central office,
noise, and so on.
Table 22 Hardware Specifications
SPECIFICATION DESCRIPTION
