ZyAIR G-2000 Plus User’s Guide
83 Chapter 6 Wireless Configuration and Roaming
Figure 25 Wireless
The following table describes the general wireless LAN labels in this screen.
Table 20 Wireless
LABEL DESCRIPTION
Enable
Wireless LAN
Click the check box to activate wireless LAN.
ESSID (Extended Service Set IDentity) The ESSID identifies the Service Set with which a
wireless station is associated. Wireless stations associating to the access point (AP)
must have the same ESSID. Enter a descriptive name (up to 32 printable 7-bit ASCII
characters) for the wireless LAN.
Note: If you are configuring the ZyAIR from a computer connected to
the wireless LAN and you change the ZyAIR’s ESSID or WEP
settings, you will lose your wireless connection when you press Apply
to confirm. You must then change the wireless settings of your
computer to match the ZyAIR’s new settings.
Hide ESSID Select this check box to hide the ESSID in the outgoing beacon frame so a station
cannot obtain the ESSID through passive scanning using a site survey tool.
Choose
Channel ID
Set the operating frequency/channel depending on your particular region.
Select a channel from the drop-down list box.
Refer to the Wizard Setup chapter for more information on channels.
RTS/CTS
Threshold
Enter a value between 0 and 2432. The default is 2432.
Fragmentation
Threshold
Enter a value between 256 and 2432. The default is 2432. It is the maximum data
fragment size that can be sent.
Apply Click Apply to save your changes back to the ZyAIR.
Reset Click Reset to reload the previous configuration for this screen.
