ZyAIR G-2000 Plus User’s Guide
73 Chapter 5 LAN Screens
Figure 18 LAN IP
The following table describes the labels in this screen.
Table 17 LAN IP
LABEL DESCRIPTION
DHCP Server DHCP (Dynamic Host Configuration Protocol, RFC 2131 and RFC 2132) allows
individual clients (computers) to obtain TCP/IP configuration at startup from a
server. Leave the DHCP Server check box selected unless your ISP instructs
you to do otherwise. Clear it to disable the ZyAIR acting as a DHCP server. When
configured as a server, the ZyAIR provides TCP/IP configuration for the clients. If
not, DHCP service is disabled and you must have another DHCP server on your
LAN, or else the computers must be manually configured. When set as a server,
fill in the following four fields.
IP Pool Starting
Address
This field specifies the first of the contiguous addresses in the IP address pool.
Pool Size This field specifies the size, or count of the IP address pool.
DNS Servers Assigned by DHCP Server
The ZyAIR passes a DNS (Domain Name System) server IP address (in the order you specify here) to
the DHCP clients. The ZyAIR only passes this information to the LAN DHCP clients when you select the
DHCP Server check box. When you clear the DHCP Server check box, DHCP service is disabled and
you must have another DHCP sever on your LAN, or else the computers must have their DNS server
addresses manually configured.
