ZyAIR G-2000 Plus User’s Guide
Chapter 3 Wizard Setup 62
3.7 Basic Setup Complete
Click Back to return to the previous screen or click Finish to complete and save the wizard
setup.
First DNS Server
Second DNS Server
Third DNS Server
Select From ISP if your ISP dynamically assigns DNS server information
(and the ZyAIR's WAN IP address). The field to the right displays the (read-
only) DNS server IP address that the ISP assigns.
Select User-Defined if you have the IP address of a DNS server. Enter the
DNS server's IP address in the field to the right.
Select None if you do not want to configure DNS servers. If you do not
configure a system DNS server, you must use IP addresses when
configuring VPN, DDNS and the time server.
WAN MAC Address The MAC address field allows you to configure the WAN port's MAC
Address by either using the factory default or cloning the MAC address
from a computer on your LAN.
Factory Default Select this option to use the factory assigned default MAC Address.
Spoof this Computer's
MAC address - IP Address
Select this option and enter the IP address of the computer on the LAN
whose MAC you are cloning. Once it is successfully configured, the
address will be copied to the rom file (ZyNOS configuration file). It will not
change unless you change the setting or upload a different rom file. It is
advisable to clone the MAC address from a computer on your LAN even if
your ISP does not presently require MAC address authentication.
Back Click Back to return to the previous screen.
Next Click Next to continue.
Table 12 Wizard 5: WAN Setup
LABEL DESCRIPTION
