ZyAIR G-2000 Plus User’s Guide
61 Chapter 3 Wizard Setup
Figure 12 Wizard 5: WAN Setup
The following table describes the labels in this screen
Table 12 Wizard 5: WAN Setup
LABEL DESCRIPTION
WAN IP Address Assignment
Get automatically from
ISP
Select this option If your ISP did not assign you a fixed IP address. This is
the default selection.
Use fixed IP address Select this option If the ISP assigned a fixed IP address. Enter a subnet
mask appropriate to your network and the gateway IP address if
applicable.
My WAN IP Address Enter your WAN IP address in this field if you selected Use Fixed IP
Address.
My WAN IP Subnet Mask Enter a Subnet Mask appropriate to your network. a
Gateway IP Address Enter the Gateway IP Address of the neighboring device, if you know it. If
you do not, leave the Gateway IP Address field as 0.0.0.0.
System DNS Server Address Assignment (if applicable)
DNS (Domain Name System) is for mapping a domain name to its corresponding IP address and vice
versa. The DNS server is extremely important because without it, you must know the IP address of a
computer before you can access it. The ZyAIR uses a system DNS server (in the order you specify
here) to resolve domain names for VPN, DDNS and the time server.
