ZyAIR G-2000 Plus User’s Guide
57 Chapter 3 Wizard Setup
PPTP supports on-demand, multi-protocol, and virtual private networking over public
networks, such as the Internet.
Refer to the appendix for more information on PPTP.
Note: The ZyAIR supports one PPTP server connection at any
given time.
Figure 11 Wizard 4: PPTP Encapsulation
The following table describes the fields in this screen
Table 9 Wizard 4: PPTP Encapsulation
LABEL DESCRIPTION
ISP Parameters for Internet Access
Encapsulation Select PPTP from the drop-down list box.
User Name Type the user name given to you by your ISP.
Password Type the password associated with the User Name above.
Nailed-Up
Connection
Select Nailed-Up Connection if you do not want the connection to time out.
Idle Timeout Type the time in seconds that elapses before the router automatically disconnects
from the PPTP server. The default is 100 seconds.
PPTP Configuration
