ZyAIR G-2000 Plus User’s Guide
Chapter 3 Wizard Setup 54
Figure 9 Wizard 4: Ethernet Encapsulation
The following table describes the labels in this screen.
Table 7 Wizard 4: Ethernet Encapsulation
LABEL DESCRIPTION
ISP Parameters for Internet Access
Encapsulation You must choose the Ethernet option when the WAN port is used as a regular
Ethernet. Otherwise, choose PPP over Ethernet or PPTP for a dial-up connection.
Service Type Choose from Standard, Telstra (RoadRunner Telstra authentication method), RR-
Manager (Roadrunner Manager authentication method), RR-Toshiba
(Roadrunner Toshiba authentication method) or Telia Login.
The following fields are not applicable (N/A) for the Standard service type.
User Name Type the user name given to you by your ISP.
Password Type the password associated with the user name above.
Login Server IP
Address
Type the authentication server IP address here if your ISP gave you one.
Login Server This field only applies when you select Telia Login in the Service Type field. Type
the domain name of the Telia login server, for example “login1.telia.com”.
Relogin Every
(min)
This field only applies when you select Telia Login in the Service Type field. The
Telia server logs the ZyAIR out if the ZyAIR does not log in periodically. Type the
number of minutes from 1 to 59 (30 default) for the ZyAIR to wait between logins.
Back Click Back to return to the previous screen.
Next Click Next to continue.
