ZyAIR G-2000 Plus User’s Guide
Chapter 35 System Maintenance and Information 364
Figure 208 Menu 24.9 System Maintenance : Call Control
Menu 24.9 - System Maintenance - Call Control
1. Budget Management
2. Call History
Enter Menu Selection Number:
35.2.1 Budget Management
Menu 24.9.1 shows the budget management statistics for outgoing calls. Enter 1 from Menu
24.9 - System Maintenance - Call Control to bring up the following menu.
Figure 209 Budget Management
Menu 24.9.3 - Budget Management
Remote Node Connection Time/Total Budget Elapsed Time/Total Period
1.ChangeMe No Budget No Budget
Reset Node (0 to update screen):
The total budget is the time limit on the accumulated time for outgoing calls to a remote node.
When this limit is reached, the call will be dropped and further outgoing calls to that remote
node will be blocked. After each period, the total budget is reset. The default for the total
budget is 0 minutes and the period is 0 hours, meaning no budget control. You can reset the
accumulated connection time in this menu by entering the index of a remote node. Enter 0 to
update the screen. The budget and the reset period can be configured in menu 11.1 for the
remote node.
Table 122 Menu 24.9.1 - Budget Management
FIELD DESCRIPTION
Remote Node Enter the index number of the remote node you want to reset (just one in this
case)
Connection Time/Total
Budget
This is the total connection time that has gone by (within the allocated budget
that you set in menu 11.1).
Elapsed Time/Total
Period
The period is the time cycle in hours that the allocation budget is reset (see
menu 11.1.) The elapsed time is the time used up within this period.
Enter “0” to update the screen or press [ESC] to return to the previous screen.
35.2.2 Call History
This is the second option in Menu 24.9 - System Maintenance - Call Control. It displays
information about past incoming and outgoing calls. Enter 2 from Menu 24.9 - System
Maintenance - Call Control to bring up the following menu.
