ZyAIR G-2000 Plus User’s Guide
Chapter 34 Firmware and Configuration File Maintenance 358
Figure 203 Menu 24.7.1 System Maintenance : Upload System Firmware
Menu 24.7.1 - System Maintenance - Upload System Firmware
To upload the system firmware, follow the procedure below:
1. Launch the FTP client on your workstation.
2. Type "open" and the IP address of your system. Then type "root" and
SMT password as requested.
3. Type "put firmwarefilename ras" where "firmwarefilename" is the name of your
firmware upgrade file on your workstation and "ras" is the remote file name on the
system.
4. The system reboots automatically after a successful firmware upload.
For details on FTP commands, please consult the documentation of your FTP
client program. For details on uploading system firmware using TFTP (note
that you must remain on this menu to upload system firmware using TFTP), please see
your manual.
Press ENTER to Exit:
34.4.2 Configuration File Upload
You see the following screen when you telnet into menu 24.7.2.
Figure 204 Menu 24.7.2 System Maintenance: Upload System Configuration File
Menu 24.7.2 - System Maintenance - Upload System Configuration File
To upload the system configuration file, follow the procedure below:
1. Launch the FTP client on your workstation.
2. Type "open" and the IP address of your system. Then type "root" and SMT password
as requested.
3. Type "put configurationfilename rom-0" where "configurationfilename" is the name of
your system configuration file on your workstation, which will be transferred to the
"rom-0" file on the system.
4. The system reboots automatically after the upload system configuration file process
is complete.
For details on FTP commands, please consult the documentation of your FTP client
program. For details on uploading system firmware using TFTP (note that you must
remain on this menu to upload system firmware using TFTP), please see your manual.
Press ENTER to Exit:
To transfer the firmware and the configuration file, follow these examples:
34.4.3 Using the FTP command from the DOS Prompt Example
1 Launch the FTP client on your computer.
2 Enter “open” and the IP address of your ZyAIR.
3 Press [ENTER] when prompted for a username.
