ZyAIR G-2000 Plus User’s Guide
357 Chapter 34 Firmware and Configuration File Maintenance
34.4 Uploading Firmware and Configuration Files
Menu 24.7 – System Maintenance – Upload Firmware allows you to upgrade the firmware
and the configuration file.
Note: WARNING! PLEASE WAIT A FEW MINUTES FOR THE
ZYAIR TO RESTART AFTER FIRMWARE OR
CONFIGURATION FILE UPLOAD. INTERRUPTING THE
UPLOAD PROCESS MAY PERMANENTLY DAMAGE YOUR
ZYAIR.
Figure 202 Menu 24.7 System Maintenance: Upload Firmware
Menu 24.7 - System Maintenance - Upload Firmware
1. Upload System Firmware
2. Upload System Configuration File
Enter Menu Selection Number:
The configuration data, system-related data, the error log and the trace log are all stored in the
configuration file. Please be aware that uploading the configuration file replaces everything
contained within.
34.4.1 Firmware Upload
FTP is the preferred method for uploading the firmware and configuration. To use this feature,
your computer must have an FTP client.
When you telnet into the ZyAIR, you will see the following screens for uploading firmware
and the configuration file using FTP.
