ZyAIR G-2000 Plus User’s Guide
Chapter 34 Firmware and Configuration File Maintenance 356
Figure 200 Menu 24.6 Restore Configuration
Menu 24.6 – Restore Configuration
To transfer the firmware and the configuration file, follow the procedure
below:
1. Launch the FTP client on your workstation.
2. Type "open" and the IP address of your router. Then type "root" and
SMT password as requested.
3. Type “put backupfilename rom-0” where backupfilename is the name of
your backup configuration file on your workstation and rom-spt is the
Remote file name on the router. This restores the configuration to your
router.
4. The system reboots automatically after a successful file transfer.
For details on FTP commands, please consult the documentation of your FTP
client program. For details on restoring using TFTP (note that you must
remain in the menu to back up using TFTP), please see your router manual.
Press ENTER to Exit:
1 Launch the FTP client on your computer.
2 Enter “open”, followed by a space and the IP address of your ZyAIR.
3 Press [ENTER] when prompted for a username.
4 Enter your password as requested (the default is “1234”).
5 Enter “bin” to set transfer mode to binary.
6 Find the “rom” file (on your computer) that you want to restore to your ZyAIR.
7 Use “put” to transfer files from the ZyAIR to the computer, for example, “put config.rom
rom-0” transfers the configuration file “config.rom” on your computer to the ZyAIR. See
earlier in this chapter for more information on filename conventions.
8 Enter “quit” to exit the ftp prompt. The ZyAIR will automatically restart after a
successful restore process.
34.3.2 Restore Using FTP Session Example
Figure 201 Restore Using FTP Session Examplei
ftp> put config.rom rom-0
200 Port command okay
150 Opening data connection for STOR rom-0
226 File received OK
221 Goodbye for writing flash
ftp: 16384 bytes sent in 0.06Seconds 273.07Kbytes/sec.
ftp>quit
Refer to section 34.2.4 to read about configurations that disallow TFTP and FTP over WAN.
