ZyAIR G-2000 Plus User’s Guide
351 Chapter 34 Firmware and Configuration File Maintenance
The following table is a summary. Please note that the internal filename refers to the filename
on the ZyAIR and the external filename refers to the filename
not on the ZyAIR, that is, on
your computer, local network or FTP site and so the name (but not the extension) will vary.
After uploading new firmware see the ZyNOS F/W Version field in Menu 24.2.1 – System
Maintenance – Information to confirm that you have uploaded the correct firmware version.
Table 119 Filename Conventions
FILE TYPE
INTERNAL
NAME
EXTERNAL
NAME
DESCRIPTION
Configuration File Rom-0 *.rom This is the configuration filename on the ZyAIR.
Uploading the rom-0 file replaces the entire ROM
file system, including your ZyAIR configurations,
system-related data (including the default
password), the error log and the trace log.
Firmware Ras *.bin This is the generic name for the ZyNOS firmware on
the ZyAIR.
34.2 Backup Configuration
Option 5 from Menu 24 – System Maintenance allows you to backup the current ZyAIR
configuration to your computer. Backup is highly recommended once your ZyAIR is
functioning properly. FTP is the preferred method, although TFTP can also be used.
Please note that the terms “download” and “upload” are relative to the computer. Download
means to transfer from the ZyAIR to the computer, while upload means from your computer to
the ZyAIR.
34.2.1 Backup Configuration Using FTP
Enter 5 in Menu 24 – System Maintenance to get the following screen.
