ZyAIR G-2000 Plus User’s Guide
341 Chapter 33 System Information and Diagnosis
33.2.2 Console Port Speed
You can set up different port speeds for the console port through Menu 24.2.2 – System
Maintenance – Console Port Speed. Your ZyAIR supports 9600 (default), 19200, 38400,
57600 and 115200 bps console port speeds. Press [SPACE BAR] and then [ENTER] to select
the desired speed in menu 24.2.2, as shown in the following figure.
Figure 193 Menu 24.2.2 System Maintenance : Change Console Port Speed
Menu 24.2.2 – System Maintenance – Change Console Port Speed
Console Port Speed: 9600
Press ENTER to Confirm or ESC to Cancel:
After you changed the console port speed on your ZyAIR, you must also make the same
change to the console port speed parameter of your communication software.
33.3 Log and Trace
Your ZyAIR provides the error logs and trace records that are stored locally.
33.3.1 Viewing Error Log
The first place you should look for clues when something goes wrong is the error log. Follow
the procedures to view the local error/trace log:
1 Type 24 in the main menu to display Menu 24 – System Maintenance.
2 From menu 24, type 3 to display Menu 24.3 – System Maintenance – Log and Trace.
ZyNOS F/W Version Refers to the ZyNOS (ZyXEL Network Operating System) system firmware
version. ZyNOS is a registered trademark of ZyXEL Communications
Corporation.
Country Code Refers to the country code of the firmware.
LAN
Ethernet Address Refers to the Ethernet MAC (Media Access Control) of your ZyAIR.
IP Address This is the IP address of the ZyAIR in dotted decimal notation.
IP Mask This shows the subnet mask of the ZyAIR.
DHCP This field shows the DHCP setting of the ZyAIR.
When you have completed this menu, press [ENTER] at the prompt “Press ENTER to confirm or ESC
to cancel” to save your configuration or press [ESC] to cancel and go back to the previous screen.
Table 116 Menu 24.2.1 System Maintenance : Information
FIELD DESCRIPTION
