ZyAIR G-2000 Plus User’s Guide
Chapter 33 System Information and Diagnosis 340
33.2 System Information
To get to the System Information:
1 Enter 24 to display Menu 24 – System Maintenance.
2 Enter 2 to display Menu 24.2 – System Information and Console Port Speed.
3 From this menu you have two choices as shown in the next figure:
Figure 191 Menu 24.2 System Information and Console Port Speed
Menu 24.2 - System Information and Console Port Speed
1. System Information
2. Console Port Speed
Note: The ZyAIR also has an internal console port for support
personnel only. Do not open the ZyAIR as it will void your
warranty.
33.2.1 System Information
Enter 1 in menu 24.2 to display the screen shown next.
Figure 192 Menu 24.2.1 System Information : Information
Menu 24.2.1 - System Maintenance - Information
Name: G-2000PLUS
Routing: IP
ZyNOS F/W Version: V3.60(HU.0)b4 | 11/16/2004
Country Code: 255
LAN
Ethernet Address: 00:A0:C5:9C:40:1C
IP Address: 192.168.1.1
IP Mask: 255.255.255.0
DHCP: Server
Press ESC or RETURN to Exit:
The following table describes the fields in this menu.
Table 116 Menu 24.2.1 System Maintenance : Information
FIELD DESCRIPTION
Name Displays the system name of your ZyAIR. This information can be changed in
Menu 1 – General Setup.
Routing Refers to the routing protocol used.
