ZyAIR G-2000 Plus User’s Guide
339 Chapter 33 System Information and Diagnosis
Figure 190 Menu 24.1 System Maintenance : Status
Menu 24.1 - System Maintenance - Status 00:55:58
Sat. Jan. 01, 2000
Port Status TxPkts RxPkts Cols Tx B/s Rx B/s Up Time
WAN Down 0 0 0 0 0 0:00:00
LAN 100M/Full 193 0 0 0 0 0:55:56
WLAN 54M 45 272 0 0 0 0:55:56
Port Ethernet Address IP Address IP Mask DHCP
WAN 00:A0:C5:9C:40:1D 0.0.0.0 0.0.0.0 Client
LAN 00:A0:C5:9C:40:1C 192.168.1.1 255.255.255.0 Server
WLAN 00:A0:C5:9C:40:1C
System up Time: 0:56:02
Name: G-2000PLUS
Routing: IP
ZyNOS F/W Version: V3.60(HU.0)b4 | 11/16/2004
Press Command:
COMMANDS: 1-Drop WAN 9-Reset Counters ESC-Exit
The following table describes the fields present in this menu.
Table 115 Menu 24.1 System Maintenance : Status
FIELD DESCRIPTION
Port This is the port type. Port types are: Ethernet and Wireless
Status This shows the status of the remote node.
TxPkts This is the number of transmitted packets to this remote node.
RxPkts This is the number of received packets from this remote node.
Cols This is the number of collisions on this connection.
Tx B/s This shows the transmission rate in bytes per second.
Rx B/s This shows the receiving rate in bytes per second.
Up Time This is the time this channel has been connected to the current remote node.
Ethernet Address This shows the MAC address of the port.
IP Address This shows the IP address of the network device connected to the port.
IP Mask This shows the subnet mask of the network device connected to the port.
DHCP This shows the DHCP setting (None or Client) for the port.
System Up Time This is the time the ZyAIR is up and running from the last reboot.
Name This displays the device name.
Routing Refers to the routing protocol used.
ZyNOS F/W
Version
Refers to the ZyNOS (ZyXEL Network Operating System) system firmware
version. ZyNOS is a registered trademark of ZyXEL Communications
Corporation.
