ZyAIR G-2000 Plus User’s Guide
Chapter 33 System Information and Diagnosis 338
CHAPTER 33
System Information and
Diagnosis
This chapter covers the information and diagnostic tools in SMT menus 24.1 to 24.4.
These tools include updates on system status, port status, log and trace capabilities and
upgrades for the system software. This chapter describes how to use these tools in detail.
Type 24 in the main menu and press [ENTER] to open Menu 24 – System Maintenance, as
shown in the following figure.
Figure 189 Menu 24 System Maintenance
Menu 24 - System Maintenance
1. System Status
2. System Information and Console Port Speed
3. Log and Trace
4. Diagnostic
5. Backup Configuration
6. Restore Configuration
7. Upload Firmware
8. Command Interpreter Mode
9. Call Control
10. Time and Date Setting
11. Remote Management Setup
Enter Menu Selection Number:
33.1 System Status
The first selection, System Status gives you information on the status and statistics of the
ports, as shown next. System Status is a tool that can be used to monitor your ZyAIR.
Specifically, it gives you information on your Ethernet and Wireless LAN status, number of
packets sent and received.
To get to System Status, type 24 to go to Menu 24 – System Maintenance. From this menu,
type 1. System Status. There are two commands in Menu 24.1 – System Maintenance –
Status. Entering 9 resets the counters; pressing [ESC] takes you back to the previous screen.
The following table describes the fields present in Menu 24.1 – System Maintenance –
Status which are read-only and meant for diagnostic purposes.
