ZyAIR G-2000 Plus User’s Guide
333 Chapter 32 System Security
Figure 185 Menu 23 System Security
Menu 23 - System Security
1. Change Password
2. RADIUS Server
4. IEEE802.1x
Enter Menu Selection Number:
From Menu 23- System Security, enter 2 to display Menu 23.2 – System Security –
RADIUS Server as shown next.
Figure 186 Menu 23.2 System Security : RADIUS Server
Menu 23.2 - System Security - RADIUS Server
Authentication Server:
Active= No
Server Address= 0.0.0.0
Port #= 1812
Shared Secret= ********
Accounting Server:
Active= No
Server Address= 0.0.0.0
Port #= 1813
Shared Secret= ********
Press ENTER to Confirm or ESC to Cancel:
The following table describes the fields in this menu.
Table 113 Menu 23.2 System Security : RADIUS Server
FIELD DESCRIPTION
Authentication Server
Active Press [SPACE BAR] to select Yes and press [ENTER] to enable user
authentication through an external authentication server.
Server Address Enter the IP address of the external authentication server in dotted decimal
notation.
Port The default port of the RADIUS server for authentication is 1812.
You need not change this value unless your network administrator instructs
you to do so with additional information.
Shared Secret Specify a password (up to 31 alphanumeric characters) as the key to be
shared between the external authentication server and the access points.
The key is not sent over the network. This key must be the same on the
external authentication server and ZyAIR.
Accounting Server
